For filling, refilling, weighing and sampling of Raw material and Compounds.
General Specification of the Sampling & Dispensing Booth.
| SR. No |
Items |
Description |
1 |
MOC |
SS 304,316. |
2 |
Pre-filter |
Air Micron Make EU 4 rating with suitable size having efficiency 90% down to 10 micron. |
3 |
Intermediate Filter |
Air Micron Make EU 7 rating with suitable size having efficiency 90% down to 3 micron. |
4 |
Mini-pleat Hepa filter |
HEPA Filter having EU 13 or EU14 rating with suitable size having efficiency 99.997& down to 0.3 micron. |
5 |
Exhaust Filter |
HEPA Filter having EU 13 or EU14 rating with suitable size having efficiency 99.997& down to 0.3 micron. |
6 |
Air Cleanliness |
Class ISO 5 (as per ISO 14644-1). |
7 |
Air Flow Rate |
0.45 + 0.1m/sec. |
8 |
Illumination Of Light |
Optimum. |
9 |
Vibration Level |
Minimum. |
10 |
Magnehelic Differential Pressure Gauge |
(make : Dwyer, USA) To measure differential pressure across the supply HEPA filter |
11 |
Motor Blower Assembly |
Statically & Dynamically balanced with suitable rating and size. (Induction motor with centrifugal blower) A Mounting unique spring suspension system to take care of vibration and noise. |
12 |
Side Panels |
Double skinned PUFF insulated side panels. |
13 |
3 Pins Switch & Socket |
15 AMPS - 1 set in each unit. |
14 |
Feather Touch Switch |
On/Off switches for motor blower & CFL lights. |
Model of the Reverse Laminar Air Flow as following.
Model |
Work space dimensions in mm |
Overall dimensions in mm |
w |
d |
h |
W |
D |
H |
| 2254-RF |
1220 |
610 |
1850 |
1400 |
1450 |
2300 |
| 2254-RF-SP-1 |
1220 |
910 |
1850 |
1400 |
1750 |
2300 |
| 2254-RF-SP-2 |
1220 |
1220 |
1850 |
1400 |
2000 |
2300 |
| 2254-RF-SP-3 |
1220 |
1525 |
1850 |
1400 |
2350 |
2300 |
| 2256-RF |
1820 |
610 |
1850 |
2050 |
1450 |
2300 |
| 2256-RF-SP-1 |
1820 |
910 |
1850 |
2050 |
1750 |
2300 |
| 2256-RF-SP-2 |
1820 |
1220 |
1850 |
2050 |
2000 |
2300 |
| 2256-RF-SP-3 |
1820 |
1525 |
1850 |
2050 |
2350 |
2300 |
| 2257-RF |
2420 |
1220 |
1850 |
2600 |
2000 |
2300 |
Factory work of the above job. |
